Fiber laser cutting machine maintenance in Winter – Alex
With the development of laser technology, more and more manufacturer start to use fiber laser cutting machine in metal cutting process. Although we said fiber laser cutting machine is free-maintenance machine. But in winter we need some measure to protective machine’s working.
The most common problems in winter is freeze. Some region’s temperature will be below 0℃ in winter. The water chillier may be freeze after stop working, so we need do some procedures to avoid this problem.
- Install air conditioner in working room and keep the temperature near 10℃.
- Keep water chillier working 24 hours. we know water can’t freeze when keep flow.
- Add glycol anti-freezing liquid in water chillier. If we add 30% anti-freezing liquid in water, freeze won’t happen even in -20℃.
Pls tale care about anti-freezing liquid can’t replace water and we can’t use it whole year. After winter, we need clean the chillier and pipe with purified water then only use purified water.
So much anti-freezing liquid will increase the resistance of water cycle, so we need add it according to temperature.
- Evacuate all water in water chillier and pipe when machine not work.
How to evacuate water
1.Switch off machine power, then open the blow-down valve and evacuate all water in refrigerator.
2.Loose the screw for drainage on water pump and evacuate all water in pump.
3.Take off the water pipe in the back of water tank. Connect 0.2Mpa gas to the water pipe end and evacuate all water in laser generator.
4.Connect 0.2Mpa gas to other water pipe and evacuate all water in fiber laser cutting head.
Take care: High gas pressure for water draining may damage fiber laser generator. so need control the pressure serious.
Change cooling water
We don’t need change cooling water frequently in winter, but also need to change it timely. Cooling water will be full of impurity if use so long time.
Except above point, also we need do regular clean for machine bed, laser cutting head and need change protective lens. For one fiber laser cutting machine, if we maintenance it well, it can work decades of years. But if we can’t do correct maintenance timely, machine may need overhaul within 10 years.
